| 特點 |
|
| 用途 |
|
單位：mm
| 型號 | 尺寸 | S | T | L1 | φD1 | φD2 | 適用扭力扳手型號 | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 25SCK | 7 | 8 | 9 | 10 | 11 | 29 | 7 | 45 | 10 | 16 |
60-250LCK, N6+N25LCK, 60--250SPCK, N6-N25SPCK, 250GCK, NA25GCK, DTC-20REV, DTC-50REV, DTC-100REV, DTC-CN200REV, DTC-CN500REV, DTC-N10REV, DTC-P140REV, DTC-P180REV |
| 12 | 13 | 14 | 15 | 16 | 32 | ||||||
| 17 | 9 | 21 | 22 | 39 | 8 | ||||||
| 24 | 27 | 45 | |||||||||
| 50SCK | 8 | 9 | 10 | 11 | 32 | 8 | 55 | 12 | 20 |
500LCK, N50LCK, 500SPCK, N50SPCK, 500GCK, N50GCK, DTC-500REV, DTC-N50REV, DTC-P1400REV, DLTN50UC |
|
| 12 | 13 | 14 | 15 | 16 | 36 | 10 | |||||
| 17 | 19 | 21 | 22 | 44 | |||||||
| 24 | 27 | 50 | |||||||||
| 100SCK | 12 | 13 | 14 | 15 | 40 | 10 | 65 | 15 | 24 |
1000LCK, N100LCK, 1000SPCK, N100SPCK, 1000, 1400GCK, N100, N140GCK, 1000BCK, 1400BCK, N100BCK, N140BCK, DTC-1000REV, DTC-N100REV, DTC-P1800REV, DLT-N100-UC |
|
| 16 | 17 | 19 | 21 | 22 | 48 | 12 | |||||
| 24 | 27 | 30 | 57 | ||||||||
| 200SCK | 17 | 19 | 21 | 22 | 56 | 14 | 80 | 18 | 28 |
2000LCK, N200LCK, 2000SPCK, N200SPCK, 2000GCK, N200GCK, DTC-2000REV, DTC-N200REV, DTC-PF100REV, DLT-N200-UC |
|
| 24 | 27 | 30 | 64 | ||||||||
| 32 | 36 | 41 | 75 | ||||||||
| 280SCK | 19 | 59 | 16 | 100 | 22 | 30 |
2800LCK, N280LCK, 2800SPCK, N280SPCK DTC-3000REV, DTC-N300REV, DTC-PF200REV |
||||
| 21 | 22 | 61 | 16 | ||||||||
| 24 | 63 | 16 | |||||||||
| 27 | 67 | 16.5 | |||||||||
| 30 | 69 | 16.5 | |||||||||
| 32 | 71 | 16.5 | |||||||||
| 36 | 75 | 18 | |||||||||
| 41 | 80 | 20 | |||||||||
| 46 | 85 | 20 | |||||||||
| 440SCK | 19 | 22 | 24 | 70 | 20 | 100 | 22 | 30 |
4400LCK, N440LCK, 4400SPCK, N440SPCK |
||
| 27 | 30 | 32 | 78 | 20 | |||||||
| 36 | 41 | 84 | 22 | ||||||||
| 46 | 94 | 22 | |||||||||
| 55 | 60 | 100 | 25 | ||||||||
| 700SCK | 22 | 24 | 80 | 25 | 125 | 30 | 41 |
5600LCK, N560LCK, 7000LCK, N700LCK DTC-5000REV, DTC-N500REV, DTC-PF400REV |
|||
| 27 | 83 | 25 | |||||||||
| 30 | 86 | 25 | |||||||||
| 32 | 88 | 25 | |||||||||
| 36 | 91 | 25 | |||||||||
| 41 | 95 | 25 | |||||||||
| 46 | 98 | 28 | |||||||||
| 50 | 102 | 28 | |||||||||
| 55 | 105 | 30 | |||||||||
| 60 | 110 | 30 | |||||||||
| 1000SCK | 27 | 84 | 30 | 130 | 34 | 45 |
8500LCK, N850LCK, 10000LCK, N1000LCK DTC-10000REV, DTC-N1000REV |
||||
| 30 | 32 | 90 | 30 | ||||||||
| 36 | 95 | 30 | |||||||||
| 41 | 100 | 30 | |||||||||
| 46 | 106 | 30 | |||||||||
| 50 | 110 | 30 | |||||||||
| 55 | 115 | 32 | |||||||||
| 60 | 120 | 32 | |||||||||
| 1500SCK | 41 | 110 | 32 | 160 | 38 | 50 |
15000LCK, N1500LCK |
||||
| 46 | 115 | 32 | |||||||||
| 50 | 120 | 32 | |||||||||
| 55 | 122 | 35 | |||||||||
| 60 | 127 | 35 | |||||||||
| 65 | 130 | 38 | |||||||||
