| 特點(diǎn) |
|
| 用途 |
|
單位：mm
| 型號(hào) | 尺寸 | S | H | G | R | L1 | φD1 | φD2 | 適用扭力扳手型號(hào) |
|---|---|---|---|---|---|---|---|---|---|
| 12QCK | 6.35（1/4"） | 24 | 19 | 7.5 | 12 | 45 | 10 | 16 |
60-250LCK, N6+N25LCK, 60--250SPCK, N6-N25SPCK, 250GCK, NA25GCK, DTC-20REV, DTC-50REV, DTC-100REV, DTC-CN200REV, DTC-CN500REV, DTC-N10REV, DTC-P140REV, DTC-P180REV |
| 25QCK | 9.53（3/8"） | 31 | 25 | 11 | 15.5 | 45 | 10 | 16 | |
| 50QCK | 9.53（3/8"） | 32 | 25 | 11 | 16 | 55 | 12 | 18 |
500LCK, N50LCK, 500SPCK, N50SPCK, 500GCK, N50GCK, DTC-500REV, DTC-N50REV, DTC-P1400REV, DLT-N50-UC |
| 100QCK | 12.7（1/2"） | 39 | 31 | 14 | 19.7 | 65 | 15 | 24 |
1000LCK, N100LCK, 1000SPCK, N100SPCK, 1000, 1400GCK, N100, N140GCK, 1000BCK, 1400BCK, N100BCK, N140BCK, DTC-1000REV, DTC-N100REV, DTC-P1800REV, DLT-N100-UC |
| 200QCK | 12.7（1/2"） | 46 | 33 | 14 | 23 | 80 | 18 | 26 |
2000LCK, N200LCK, 2000SPCK, N200SPCK, 2000GCK, N200GCK, DTC-2000REV, DTC-N200REV, DTC-PF100REV, DLT-N200-UC |
| 280QCK-A | 19.05（3/4"） | 54 | 42.5 | 20 | 27 | 100 | 22 | 30 |
2800LCK, N280LCK, 2800SPCK, N280SPCK DTC-3000REV, DTC-N300REV, DTC-PF200REV |
| 440QCK | 19.05（3/4"） | 54 | 42.5 | 20 | 27 | 100 | 22 | 30 |
4400LCK, N440LCK, 4400SPCK, N440SPCK |
| 700QCK | 19.05（3/4"） | 68 | 50 | 20 | 34 | 125 | 30 | 410 |
5600LCK, N560LCK, 7000LCK, N700LCK DTC-5000REV, DTC-N500REV, DTC-PF400REV |
| 1000QCK | 25.4（1"） | 76 | 58 | 27 | 38 | 130 | 34 | 45 |
8500LCK, N850LCK, 10000LCK, N1000LCK DTC-10000REV, DTC-N1000REV |
| 2100QCK | 25.4（1"） | 87 | 61 | 28.5 | 43.5 | 160 | 38 | 52 |
15000LCK, N1500LCK |
